A High Yield Strength steel for welded and weight – saving structures

Bozhong® Ultra 890 is a quenched and tempered steel for structure with higher strength. Thanks to a minimum yield strength of 890 N/mm² (130 ksi), Bozhong® Ultra 890 enables to make weight savings or support higher stresses and thus carry higher payload.

With a good quality of steel making process, an adapted chemical analysis (low alloying content) and an excellent precision in our fabrication process (thickness tolerance, uniform mechanical characteristics), Bozhong® Ultra 890 is easy to machine, to bend and to weld which simplify production and maintenance.

By using Bozhong® Ultra 890 and thus thinner plate in welded structures, you limit preheating conditions, you decrease quantity of consumables, welding time and so production costs.

Standards
Bozhong® Ultra 890 fulfills the requirements of S890QL according to EN 10025-6 standard, last edition.

Chemical Analysis
Typical values (weight %)
C Mn Si Cr Mo P S V Ni Cu Al
0.19 1.50 0.50 0.70 0.70 .020 .010 .10 1.6 .30 .04 to .080

Carbon Equivalent
Thickness range – mm (*) C.Eq
6 – 50 (.24″ – 2″) ≤ .59
50.1 – 125 (2″ – 4.92″) ≤ .70

Mechanical Properties
Thickness Y.S. 0.2 N/mm²(ksi) UTS N/mm²(ksi) Elongation A 5%
6 – 50 (.24“ – 2“) 890 (130) 940 – 1100 (137 – 160) 11
50.1 – 125 (2“ – 4.92“) 830 (120) 880 – 1100 (128 – 159) 11
Very High Strength (890mpa)
