A High Yield Strength steel for welded and weight – saving structures

Bozhong® Ultra 1100 is a quenched and tempered steel for structure with higher strength. Thanks to a minimum yield strength of 1100 N/mm², Bozhong® Ultra 1100 enables to make weight savings or support higher stresses and thus carry higher payload.

With a good quality of steel making process, an adapted chemical analysis (low alloying content) and a good manufacturing process (uniform mechanical characteristics), Bozhong®Ultra 1100 is easy to machine, to bend and to weld which simplify production and maintenance.

Standards

Bozhong® Ultra 1100 is produced as per Industeel technical data sheet.

Chemical Analysis
Typical Values (weight %)

C	Mn	Si	Cr	Mo	P	S	V	Ni	Cu	Al
.20	1.4	0.3	0.7	0.65	0.010	0.005	0.010	2.0	0.20	0.05 to 0.080

Carbon Equivalent

Thickness range – mm (*)	C.Eq
8 – 15 mm	≤ 0.75

Mechanical Properties

Thickness	Mp 0.2/Y.S. 0.2 N/mm²(ksi)	UTS N/mm²(ksi)	Elongation A 5%
8 – 15 mm	1100 (160)	1250 – 1450 (181 – 210)	10
